GIANT TRANCE X ADVANCED E+ ELITE 3 (2024) - HELIOS ORANGE
GIANT TRANCE X ADVANCED E+ ELITE 3 (2024) - HELIOS ORANGE

GIANT TRANCE X ADVANCED E+ ELITE 3 (2024) - HELIOS ORANGE

Regular price$8,999.00
/
Tax included. Shipping calculated at checkout.

Size

*PLEASE NOTE SHIPPING IS NOT AVAILABLE ON ALL GIANT & LIV BIKES*

ACCELERATE UP CLIMBS, FLOAT THROUGH ROCK GARDENS, AND EXPERIENCE MORE POWER, AGILITY AND CONTROL WITH THIS LIGHTWEIGHT, FULL-SUSPENSION E-MTB. THE ULTRA-SLIM BATTERY MINIMIZES WEIGHT SO YOU CAN RIDE TECHNICAL TRAILS THE WAY YOU ALWAYS DREAMED OF.

KEY PERFORMANCE FACTORS

Lighter weight

EnergyPak 400 battery system is ultra slim, delivering all the power you need, but in a smaller package that’s cleanly integrated into the lightweight composite frameset.

Advanced cockpit control

RideControl Ergo 3 remote attaches to the composite Giant Contact handlebar. The control can be mounted to either side of the handlebar so you can customise your controls for a clean, uncluttered cockpit.

More power

New SyncDrive Pro Magnesium motor features a magnesium casing that reduces weight by 50g. It weighs just 2.5kg and delivers 85Nm of torque while retaining the instant engagement that characterises SyncDrive Pro motors. It’s also engineered for a reduced noise level and quiet performance.

SPECIFICATIONS

  • Motor
    SyncDrive Pro2, 85Nm, powered by Yamaha
  • Battery
    EnergyPak Smart 400Wh EnergyPak Plus, range extender compatible
  • Charger
    EnergyPak 4A smart charger compact
  • Controller
    RideControl Ergo 3, grip integrated
  • Display
    RideControl GO, frame integrated LED display ANT+ Wireless display compatible
  • Sizes
    S, M, L, XL
  • Colours
    Helios Orange
  • Frame
    Advanced-Grade Composite front triangle, ALUXX SL-Grade rear triangle, 140mm Maestro suspension, flip chip, UDH hanger 12x148mm thru-axle
  • Fork
    Marzocchi Bomber Z2 E-Tuned, 29er, 150mm travel, 44mm offset, RAIL damper Sweep-Adj, Kabolt 110
  • Shock
    Fox Float Performance, EVOL Large Volume sleeve, 2pos, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30%
  • Handlebar
    Giant Contact SL 35 Trail, 35mm
  • Stem
    Giant Contact SL 35 S:40mm, M:40mm, L:40mm, XL:50mm
  • Seatpost
    TranzX travel-adjustable dropper, remote S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm L: 170-200mm travel / 30.9 x 559mm XL: 170-200mm travel / 30.9 x 559mm
  • Saddle
    Giant Romero
  • Pedals
    N/A
  • Shifters
    Shimano Deore
  • Front Derailleur
    MRP HD2 co-moulded chain guide
  • Rear Derailleur
    Shimano Deore 12-speed, Shadow+
  • Brakes
    Shimano BR-MT420, 4-piston, hydraulic disc,203mm [F/R]
  • Brake Levers
    Shimano Deore, I-spec EV
  • Cassette
    Shimano CS-M6100-12, 10-51T, 12-speed
  • Chain
    KMC e.12 Turbo, EcoProteq, e-bike optimised
  • Crankset
    Praxis Wave 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set S:160mm, M: 165mm, L:165mm, XL:170mm
  • Bottom Bracket
    N/A
  • Rims
    Giant AM30, Tubeless ready, 30mm inner width, 29" [F] / 27.5" [R]
  • Hubs
    Shimano MT410 Boost, Center-Lock, 110x15 [F] 148x12 Shimano Micro-Spline Drive Body Thru-axle [R]
  • Spokes
    Sapim, e-bike optimised
  • Tires
    Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F]Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
  • Extras
    Tubeless kit (liquid, valves, levers)
